The TSP polymer strain relief range of cable glands are suitable for use in industrial (safe) areas with unarmoured or braided cable when terminated inside the enclosure, and have a temperature rating of +100°c to -60°c.

With the widest cable sealing range on the market, the TSP reduces the need to purchase a range of different sized cable glands for a project, reducing the overall cost.

The TSP range meets the requirements of well-known cable gland standards including EN 62444 and IEC 62444.

For more specific applications IP68 & IP69X ingress discs or plugs are available, as well as a flame retardant UL94 V-0 option.

Features include:

  • Halogen and phosphorus free
  • Finger-locking seal provides superior cable retention & strain relief
  • 3rd party certified to IEC 62444 and EN 62444
  • Flame retardant UL94 V-0 version available
  • Low weight with high stiffness and strength
  • Widest cable range take for any comparable cable gland
  • Available in a variety of colours (black as standard, see table to the left)
  • Anti-vibration technology prevents gland loosening in operation
  • Transit disc or IP68, IP69 & IP69K rated IP plug options available
  • Approved entry thread sealing washer included
  • Polyamide locknut available (ordering suffix 2TN) – delivered assembled

Tightening tools may be required to aid installation. For further information, please click here.

View further details on the TruSeal strain relief cable gland range here.

Design Specification IEC 62444, EN 62444 (EN Metric only)
Mechanical Classifications* 12-16 Impact = Level 4, 20-63 Impact = Level 6, Cable Anchorage = Type A
Enclosure Protection 12-16 IK07 to IEC 62262 (contact CMP for specific impact)
20-63 IK08 to IEC 62262 (7 joules)
Ingress Protection Rating** IP66, IP67, IP68**, IP69 & IP69K
Cable Gland Material Halogen-free Polyamide
Seal Material CMP SOLO LSF Halogen-free Thermoset Elastomer
Cable Type Unarmoured & Braided (when braid is terminated inside enclosure)
Sealing Technique CMP Unique finger-locking type seal
Sealing Area(s) Cable Outer Sheath

* Mechanical classifications applied as per IEC/EN 62444
** IP68 tested to 300 kPa for 16 hours (equivalent to 30 metres water depth)

Jump to technical illustration

Click here to view how to order

Dual Seal Available Entry Threads 'C'Overall Cable Diameter 'A'Across Flats 'D'Across Corners 'D'ShroudProtrusion Length 'B'Minimum Order Quantity
StandardOption
Cable Gland OnlyCable Gland with LocknutMetricThread Length (Metric) 'E'Long Thread Length (Metric) 'E'NPTThread Length (NPT) 'E'MinMaxMaxMax
16DTSP1TA16DTSP2TNM169.015.03⁄8”11.03.010.019.020.9-27.0100
20DTSP1TA20DTSP2TNM2010.015.01⁄2”14.05.014.024.026.2LSF04/PVC0430.5100
25DTSP1TA25DTSP2TNM2510.015.03⁄4”15.09.018.030.032.7LSF06/PVC0636.050
32DTSP1TA32DTSP2TNM3212.015.01”18.012.525.040.043.6LSF10/PVC1041.010
40DTSP1TA40DTSP2TNM4012.018.01 1⁄4”18.019.032.050.054.5LSF13/PVC1349.010
50DTSP1TA50DTSP2TNM5012.018.01 1⁄2”19.022.038.058.063.2LSF16/PVC1659.05
63DTSP1TA63DTSP2TNM6315.018.02”20.028.048.068.074.1LSF17/PVC1764.01
Standard Seal Available Entry Threads 'C'Overall Cable Diameter 'A'Across Flats 'D'Across Corners 'D'ShroudProtrusion Length 'B'Minimum Order Quantity
StandardOption
Cable Gland OnlyCable Gland with LocknutMetricThread Length (Metric) 'E'Long Thread Length (Metric) 'E'NPTThread Length (NPT) 'E'MinMaxMaxMax
12TSP1TA12TSP2TNM129.015.01⁄4”11.03.06.515.016.4-27.0100
16STSP1TA16STSP2TNM169.015.03⁄8”11.03.07.019.020.9-27.0100
16TSP1TA16TSP2TNM169.015.03⁄8”11.06.010.019.020.9-27.0100
20STSP1TA20STSP2TNM2010.015.01⁄2”14.05.010.024.026.2LSF04/PVC0430.5100
20TSP1TA20TSP2TNM2010.015.01⁄2”14.09.014.024.026.2LSF04/PVC0430.5100
25STSP1TA25STSP2TNM2510.015.03⁄4”15.09.015.530.032.7LSF06/PVC0636.050
25TSP1TA25TSP2TNM2510.015.03⁄4”15.012.518.030.032.7LSF06/PVC0636.050
32STSP1TA32STSP2TNM3212.015.01”18.012.519.040.043.6LSF10/PVC1041.010
32TSP1TA32TSP2TNM3212.015.01”18.017.025.040.043.6LSF10/PVC1041.010
40STSP1TA40STSP2TNM4012.018.01-1⁄4”18.019.027.050.054.5LSF13/PVC1349.010
40TSP1TA40TSP2TNM4012.018.01-1⁄4”18.024.032.050.054.5LSF13/PVC1349.010
50STSP1TA50STSP2TNM5012.018.01-1⁄2”19.022.032.058.063.2LSF16/PVC1659.05
50TSP1TA50TSP2TNM5012.018.01-1⁄2”19.028.038.058.063.2LSF16/PVC1659.05
63STSP1TA63STSP2TNM6315.018.02”20.028.039.068.074.1LSF16/PVC1764.01
63TSP1TA63TSP2TNM6315.018.02”20.037.048.068.074.1LSF16/PVC1764.01
For NPT threads add a ‘T’ to the suffix e.g. 16DTSP1TAT (3⁄8” NPT, black), 40DTSP1TAT1 (1 1⁄4” NPT, grey (silver))
For long metric threads add an ‘L’ to the suffix e.g. 16DTSP1TAL (M16, black with 15mm length of entry thread).
Dimensions are displayed in millimetres unless otherwise stated.

Technical Illustration
