- TSPe Ex i | Ex eb, Ex ta | Strain Relief Plastic Cable Gland
- Ex ta
-
IP66, 67, 68, 69K
-
+95°C to -40°C
TSPe Ex i | Ex eb, Ex ta | Strain Relief Plastic Cable Gland For all Types of Unarmoured & Braided / Screened Cables
We'd like to keep in touch
We have some exciting things in the pipeline - if you'd like to be the first to know please enter your email address below.
- Blue nut for Intrinsically safe (Ex i) identification
- Halogen and phosphorus-free
- Finger-locking seal provides superior cable retention and strain relief
- Approved to the latest editions of IEC/EN 60079
- Internationally marked IECEx and ATEX
- 3rd party certified to IEC/EN 62444
- Widest cable range take for any comparable cable gland
- Low weight with high stiffness and strength
- Anti-vibration technology prevents seal loosening in operation
- Transit disc or IP68, IP69 and IP69K rated IP plug options available
- Approved entry thread sealing washer included
- For clearance holes the TSPe must be installed using a CMP metallic locknut (available with the cable gland using ordering suffix 2TN)
| Design Specification | IEC 62444, EN 62444 (EN Metric only) |
| Mechanical Classifications* | 12-16 Impact = Level 5, 20-63 Impact = Level 6, Cable Anchorage = Type A |
| Enclosure Protection | 12-16 IK07 to IEC 62262 (4 joules), 20-63 IK08 to IEC 62262 (7 joules) |
| Ingress Protection Rating ** | IP66, IP67, IP68**, IP69 & IP69K |
| Cable Gland Material | Halogen-free Polyamide |
| Seal Material | CMP SOLO LSF Halogen-free Thermoset Elastomer |
| Cable Type | Unarmoured & Braided when terminated inside enclosure |
| Sealing Technique | CMP Unique finger-locking type seal |
| Sealing Area(s) | Cable Outer Sheath |
| ATEX Certificate | CML 19ATEX3185X |
| Compliance Standards | EN 60079-0,7,31 |
| Code of Protection | II 2G 1D, Ex eb IIC Gb, Ex ta IIIC Da |
| IECEx Certificate | IECEx CML 19.0062X |
| Code of Protection | Ex eb IIC Gb, Ex ta IIIC Da |
| Compliance Standards | IEC 60079-0,7,31 |
| EAC Certificate | RU C-GB. AД07.B.02516/20 |
| SANS | IA S-XPL21804 21.0014X |
| Marine Approvals | TAE000000Y |
| CCC Certificate | 2020322313003450 |
| ECAS Certificate | 24-03-106290/E24-03-110155/NB0007 |
| UKEX Certificate | CML 21UKEX3264X |
* Mechanical classifications applied as per IEC/EN 62444
** IP68 tested to 300 kPa for 16 hours (equivalent to 30 metres water depth)
Certificates
Click here to view how to order
| Dual Seal | Available Entry Threads 'C' | Overall Cable Diameter 'A' | Across Flats 'D' | Across Corners 'D' | Protrusion Length 'B' | |||||
| Standard | Option | |||||||||
| Cable Gland Ordering Ref | Metric | Thread Length (Metric) 'E' | Long Thread Length (Metric) 'E' | NPT | Thread Length (NPT) 'E' | Min | Max | Max | Max | |
| 16DTSPE1TA4 | M16 | 9.0 | 15.0 | 3⁄8” | 11.0 | 3.2 | 10.0 | 19.0 | 20.9 | 27.0 |
| 20DTSPE1TA4 | M20 | 10.0 | 15.0 | 1⁄2” | 14.0 | 5.5 | 14.0 | 24.0 | 26.2 | 30.5 |
| 25DTSPE1TA4 | M25 | 10.0 | 15.0 | 3⁄4” | 15.0 | 9.0 | 18.0 | 30.0 | 32.7 | 36.0 |
| 32DTSPE1TA4 | M32 | 12.0 | 15.0 | 1” | 18.0 | 12.5 | 25.0 | 40.0 | 43.6 | 41.0 |
| 40DTSPE1TA4 | M40 | 12.0 | 18.0 | 1 1⁄4” | 18.0 | 19.0 | 32.0 | 50.0 | 54.5 | 49.0 |
| 50DTSPE1TA4 | M50 | 12.0 | 18.0 | 1 1⁄2” | 19.0 | 22.0 | 38.0 | 58.0 | 63.2 | 59.0 |
| 63DTSPE1TA4 | M63 | 15.0 | 18.0 | 2” | 20.0 | 28.0 | 48.0 | 68.0 | 74.1 | 64.0 |
| Dual Seal | Available Entry Threads 'C' | Overall Cable Diameter 'A' | Across Flats 'D' | Across Corners 'D' | Protrusion Length 'B' | |||||
| Standard | Option | |||||||||
| Cable Gland Ordering Ref | Metric | Thread Length (Metric) 'E' | Long Thread Length (Metric) 'E' | NPT | Thread Length (NPT) 'E' | Min | Max | Max | Max | |
| 12TSPE1TA4 | M12 | 9.0 | 15.0 | 1⁄4” | 11.0 | 3.0 | 6.5 | 15.0 | 16.4 | 27.0 |
| 16STSPE1TA4 | M16 | 9.0 | 15.0 | 3⁄8” | 11.0 | 3.0 | 7.0 | 19.0 | 20.9 | 27.0 |
| 16TSPE1TA4 | M16 | 9.0 | 15.0 | 3⁄8” | 11.0 | 6.0 | 10.0 | 19.0 | 20.9 | 27.0 |
| 20STSPE1TA4 | M20 | 10.0 | 15.0 | 1⁄2” | 14.0 | 5.0 | 10.0 | 24.0 | 26.2 | 30.5 |
| 20TSPE1TA4 | M20 | 10.0 | 15.0 | 1⁄2” | 14.0 | 9.0 | 14.0 | 24.0 | 26.2 | 30.5 |
| 25STSPE1TA4 | M25 | 10.0 | 15.0 | 3⁄4” | 15.0 | 9.0 | 15.5 | 30.0 | 32.7 | 36.0 |
| 25TSPE1TA4 | M25 | 10.0 | 15.0 | 3⁄4” | 15.0 | 12.5 | 18.0 | 30.0 | 32.7 | 36.0 |
| 32STSPE1TA4 | M32 | 12.0 | 15.0 | 1” | 18.0 | 12.5 | 19.0 | 40.0 | 43.6 | 41.0 |
| 32TSPE1TA4 | M32 | 12.0 | 15.0 | 1” | 18.0 | 17.0 | 25.0 | 40.0 | 43.6 | 41.0 |
| 40STSPE1TA4 | M40 | 12.0 | 18.0 | 1 1⁄4” | 18.0 | 19.0 | 27.0 | 50.0 | 54.5 | 49.0 |
| 40TSPE1TA4 | M40 | 12.0 | 18.0 | 1 1⁄4” | 18.0 | 24.0 | 32.0 | 50.0 | 54.5 | 49.0 |
| 50STSPE1TA4 | M50 | 12.0 | 18.0 | 1 1⁄2” | 19.0 | 22.0 | 32.0 | 58.0 | 63.2 | 59.0 |
| 50TSPE1TA4 | M50 | 12.0 | 18.0 | 1 1⁄2” | 19.0 | 28.0 | 38.0 | 58.0 | 63.2 | 59.0 |
| 63STSPE1TA4 | M63 | 15.0 | 18.0 | 2” | 20.0 | 28.0 | 39.0 | 68.0 | 74.1 | 64.0 |
| 63TSPE1TA4 | M63 | 15.0 | 18.0 | 2” | 20.0 | 37.0 | 48.0 | 68.0 | 74.1 | 64.0 |
| For NPT threads add a ‘T’ to the suffix e.g. 16DTSPE1TA4T (3⁄8” NPT) For long metric threads add an ‘L’ to the suffix e.g. 16DTSPE1TA4L (M16, with 15mm length of entry thread. |
||||||||||
| Dimensions are displayed in millimetres unless otherwise stated | ||||||||||
